- Single phase mators are widely used in home appliances They are operated directly by switch MCB or machanical starters which does not provide sufficient Protetion to motors and does not isolate the appliances in case of power failure.
- Facility :- Fully microcontroller based technology, 7 segment LED display for displaying volt & amp.electronic start stop facility,high & low voltage protection, over load protection, dryrun protection(optional), cyclic timer(optional)off timer (optional), application:- air conditioner, aata maker, pressure pump, monoblock motor,industrial and domestic
- Appliction current range:- over load= 4-20 amp, dryrun = 0-20 amp,
- Low Voltage (below 290v) high voltage (above 480v) & over load protection. (As per inverse time current characteristics.) SPP (single phasing protection) Up to motor terminal (within 4 to 7 second.) Variable current (Amp.) Setting. Indication of motor On Low Volt, High Volt. Over Load can be use up to 7.5 HP DOL Motor/Pumps.
